Display II LED Ceiling Panel 300×600 mm 22W

Display II LED Ceiling Panel 300×600 mm 22W

The Display II LED ceiling panel in 300×600 mm is the narrow member of the series, sized for half-module ceiling tiles. Choose it for hallways, lobbies, dry office washrooms and small rooms where a full square panel is too much light. Facility teams use it to retire ageing fluorescent fittings tile by tile.

Benefits

• Half-module fit: the 300 x 600 mm body covers narrow tiles without adapters.
• Known light level: approx. 120 lux at desk height, 80 cm above the floor, mounted at 2.4 m with cool white LEDs.
• 22W at minimum 100 lm/W: low load for hallways and circulation areas.
• Painted anodised aluminium: a white finish that keeps its appearance over years of service.
• UV-resistant diffuser: clear polycarbonate that resists yellowing under daylight.
• Three ways to mount: grid ceiling, plasterboard cut-out or surface with clips on request.

Technical specifications

• Body material: anodised aluminium, electrostatically painted
• Diffuser: clear polycarbonate, UV resistant
• Body colour: standard white
• Total power: 22W
• Luminous efficacy: minimum 100 lm/W (neutral white and cool white)
• Illuminance: approx. 120 lux at 80 cm above the floor, mounted at 2.4 m, cool white
• Colour rendering index: 80 for neutral and warm white, 70 for cool white
• Supply: 230V AC, 50/60Hz
• Driver: external, outside the body
• Electrical insulation class: I
• Ingress protection: IP40
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 300 x 600 x 16 mm
• Mounting: grid ceiling, recessed in plasterboard or surface mounted (clips on request)
• Markings: CE, F-Mark; indoor use

Applications and installation

The panel covers commercial, residential, office, school, hospital and industrial interiors, including dry production spaces. Drop it into a 300 x 600 mm tile, cut it into plasterboard, or clip it to the soffit. The F-Mark permits direct mounting on normally flammable surfaces. Keep the external driver accessible above the false ceiling for later service. Because protection is IP40, reserve this Display II LED ceiling panel for dry, air-conditioned rooms. It is designed and produced in Europe.

Frequently asked questions

Where is 22W enough? In hallways, corridors, changing rooms, dry washrooms and small rooms, where 120 lux at table height does the job. For offices, combine several units or move to the 600 x 600 mm format.

Can I mix it with the 600 x 600 mm panels? Yes. The series shares the same 16 mm depth, white body and diffuser, so the ceiling reads as one system.

Is the driver inside? No. The power supply is external and sits above the false ceiling or next to the luminaire.
