Cerber Bidirectional LED Spotlight 6 LEDs 6-18W

Cerber Bidirectional LED Spotlight 6 LEDs 6-18W

The Cerber bidirectional LED spotlight throws light in two directions, and you set the colour and the beam of each side separately. Architects and retail designers use it to graze a wall in one direction and pick out a column in the other. Six OSRAM LEDs deliver 6W or 18W from a single fixing point.

Benefits

• Two independent beams: configure a different colour and focus for each direction.
• Seven LED colours: warm white 3000 K, neutral white 4000 K, cool white 5000 K, red 650 nm, green 523 nm, blue 470 nm and amber 617 nm.
• Optional DMX RGB: order the spotlight with RGB LEDs driven over DMX for programmed colour scenes.
• Four beam types: dedicated lenses give wide, medium, narrow or elliptical distribution.
• Compact body: 65 mm diameter, 135 mm long, 0.6 kg, so it stays discreet on a wall.
• Finish to match the scheme: black as standard, with white, grey or any RAL on request.

Technical specifications

• Body material: electrostatically painted aluminium
• Diffuser: clear polycarbonate
• Body colour: standard black; white, grey or another RAL on request
• Light source: 6 OSRAM LEDs
• Total power: 6W | 18W
• LED colour (configurable): warm white 3000 K, neutral white 4000 K, cool white 5000 K, red 650 nm, green 523 nm, blue 470 nm, amber 617 nm; optional DMX-controlled RGB
• Beam (configurable): wide, medium, narrow or elliptical
• Luminous efficacy: minimum 100 lm/W for white
• Colour rendering index: 80 for neutral and warm white, 70 for cool white
• Supply: 230V AC, 50/60Hz
• Driver: internal
• Power factor: minimum 0.9
• Electrical protection class: III
• Optical compartment protection: IP40
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 65 mm diameter, 135 mm long
• Weight: 0.6 kg
• Markings: CE, F-Mark; indoor use

Applications and installation

Use this bidirectional LED spotlight in architectural, retail, residential, office, school and hospital projects, for accent and general interior light. Fix it to any flat surface: a wall, a column or a beam. The F-Mark allows direct mounting on normally flammable surfaces. Protection of the optical compartment is IP40, so keep the spotlight indoors, in dry and conditioned spaces. Specify colour, beam and any DMX option per direction at order stage. The luminaire is engineered and built in Europe.

Frequently asked questions

Can one side be white and the other blue? Yes. Each direction is configured separately for colour and for beam angle.

Does it work in a DMX installation? On request the spotlight is fitted with RGB LEDs controlled over DMX, for programmed colour sequences.

When do I choose 6W over 18W? 6W covers short-throw accents. 18W suits tall walls or elliptical beams across large surfaces.
