Galaxy Linear LED Floodlight 6 LEDs 6-15W

Galaxy Linear LED Floodlight 6 LEDs 6-15W

The Galaxy linear LED floodlight with 6 LEDs is a 220 mm architectural body for facades, columns and garden walls. It fits architects, commercial developers and owners who want lines of light on vertical surfaces. Dedicated lenses and a rotating body give precise aiming without extra accessories.

Benefits

• Compact line of light: 220 mm long and 0.9 kg, easy to integrate into profiles or under cornices.
• Two power levels: 1 W or 2.5 W per LED, drawing 4 W or 10 W from the mains.
• Beam controlled by lenses: wide, medium, narrow or elliptical focus.
• Accent colours: three shades of white plus red, green, blue and orange.
• Outdoor durability: minimum IP66 and IK10, with a 3 mm UV-protected diffuser.
• Aim after mounting: the body rotates to the required angle on its aluminium bracket.

Technical specifications

• Housing material: powder-coated aluminium
• Housing colour: grey as standard, other colours on customer request
• Diffuser: clear 3 mm polycarbonate, UV protected
• Mounting bracket: powder-coated aluminium, rotating
• Light source: OSRAM LEDs with lenses
• Number of LEDs: 6
• Power per LED: 1 W or 2.5 W
• Total power: 6 W or 15 W
• Mains consumption: 4 W or 10 W, according to the version chosen
• LED colours: warm white 3000 K, neutral white 4000 K, cool white 5000 K, red 650 nm, green 523 nm, blue 470 nm, orange 617 nm
• Beam focus: wide, medium, narrow, elliptical
• Efficacy: minimum 100 lm/W for white light
• CRI: 80 for neutral and warm white, 70 for cool white
• Supply: 230 V AC, 50/60 Hz standard; 12-24 V AC/DC optional
• Supply cable length: 2 m
• Insulation class: I
• Ingress protection: minimum IP66
• Impact resistance: IK10
• Operating temperature: -20 degrees C to +40 degrees C
• Length: 220 mm
• Weight: 0.9 kg
• Compliance: CE marking, RoHS, F mark for mounting on normally flammable surfaces, outdoor use

Applications and installation

The unit serves commercial, residential, public and architectural projects, for facade and garden lighting. Mount it at the base of a wall for a vertical wash, or under a cornice for downward light. The elliptical focus spreads the beam sideways, which helps on wide facades. Align several bodies to build a continuous line. Minimum IP66 protects the optics against dust and driving rain, and the UV-protected diffuser holds its clarity in strong sun.

Frequently asked questions

What is the real consumption? 4 W in the 1 W LED version and 10 W in the 2.5 W LED version, measured at the mains.

Can I run the unit on 24 V? Yes. On request it is built for 12 or 24 V AC/DC. The standard supply is 230 V AC.

Which focus suits a 6 m facade? Narrow or medium, so the light climbs the wall. For low walls use the wide focus.
