Galaxy Linear LED Floodlight 12 LEDs 12-30W

Galaxy Linear LED Floodlight 12 LEDs 12-30W

The Galaxy linear LED floodlight with 12 LEDs is the 470 mm version of the series, built for architectural, general and access route lighting. It serves facade designers, facility managers and installers who need a linear body with an integrated driver. The longer housing covers surfaces that the short version cannot reach.

Benefits

• Double the coverage: 12 OSRAM LEDs across 470 mm, in a 12 W or 30 W build.
• Driver inside the housing: the built-in power unit simplifies the 230 V AC connection.
• Predictable consumption: 16 W or 40 W from the mains, according to the LED rating you select.
• Lens optics: wide, medium, narrow or elliptical focus for facades, walkways or parapets.
• Colour palette: warm, neutral or cool white, plus red, green, blue and orange for lighting scenes.
• Built for outdoors: minimum IP66, IK10 and a 3 mm UV-protected diffuser.

Technical specifications

• Housing material: powder-coated aluminium
• Housing colour: grey as standard, other colours on customer request
• Diffuser: clear 3 mm polycarbonate, UV protected
• Mounting bracket: powder-coated aluminium, rotating
• Light source: OSRAM LEDs with lenses
• Number of LEDs: 12
• Power per LED: 1 W or 2.5 W
• Total power: 12 W or 30 W
• Mains consumption: 16 W or 40 W
• LED colours: warm white 3000 K, neutral white 4000 K, cool white 5000 K, red 650 nm, green 523 nm, blue 470 nm, orange 617 nm
• Beam focus: wide, medium, narrow, elliptical
• Efficacy: minimum 100 lm/W for white light
• CRI: 80 for neutral and warm white, 70 for cool white
• Supply: 230 V AC, 50/60 Hz standard; 12-24 V AC/DC optional
• Power unit: included, inside the housing
• Supply cable length: 2 m
• Insulation class: I
• Ingress protection: minimum IP66
• Impact resistance: IK10
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 470 x 54 x 200 mm
• Weight: 1.2 kg
• Compliance: CE marking, RoHS, F mark for mounting on normally flammable surfaces, outdoor use

Applications and installation

Mount the unit on facades for architectural lighting, and equally for general and access route lighting: walkways, ramps and building entrances. The aluminium bracket rotates to the angle you set. On tall facades use the narrow focus; on walkways use the wide or elliptical beam. The F mark allows direct mounting on normally flammable surfaces. Minimum IP66 keeps wind-driven dust and driving rain out of the optical chamber.

Frequently asked questions

How does it differ from the 6 LED model? Twice the LED count, a 470 mm body instead of 220 mm and the power unit inside the housing. Consumption rises to 16 W or 40 W.

Can I use it on a walkway? Yes. With the wide or elliptical focus it lights access routes and circulation areas.

How is the power selected? At order you choose between 1 W LEDs, giving 12 W total, and 2.5 W LEDs, giving 30 W.
