Micro LED Wall Light 1-3 LEDs IP44 Outdoor

Micro LED Wall Light 1-3 LEDs IP44 Outdoor

The Micro LED wall light with 1, 2 or 3 LEDs is a general lighting fitting for garages, cellars, warehouses, production halls and perimeters. It answers industrial facility managers and homeowners with damp outbuildings. IP44 protection and a UV-resistant plastic housing replace fittings that rust or degrade in humid air.

Benefits

• Power scaled to the room: 2.5 W, 5 W or 7.5 W, according to the number of LEDs you order.
• Light in every direction: omnidirectional distribution, suited to general lighting in small rooms.
• Handles humidity: IP44 as standard, and the fitting can be built to IP65 on request.
• No earthing needed: insulation class II through the enclosure, so installation is simpler.
• Two supply options: 230 V AC as standard or 12-24 V DC for low voltage installations.
• Good white light efficacy: minimum 100 lm/W with warm, neutral or cool white OSRAM LEDs.

Technical specifications

• Housing material: UV-resistant plastic
• Housing colour: grey as standard
• Diffuser: clear glass
• Light source: OSRAM LEDs
• Number of LEDs: 1, 2 or 3
• Total power: 2.5 W, 5 W or 7.5 W
• LED colours: warm white 3000 K, neutral white 4000 K, cool white 5000 K
• Beam focus: omnidirectional
• Efficacy: minimum 100 lm/W for white light
• CRI: 80 for neutral and warm white, 70 for cool white
• Supply: 230 V AC standard or 12-24 V DC
• Power unit: included, inside the housing
• Supply cable length: 2 m
• Insulation class: II
• Ingress protection: IP44, IP65 on request
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 230 x 230 x 49 mm
• Weight: 0.6 kg
• Markings: CE, F mark for mounting on normally flammable surfaces, outdoor use

Applications and installation

The Micro LED wall light serves industrial and residential projects, for warehouse lighting, perimeter lighting and production area lighting. Mount it on a wall or ceiling, indoors or outdoors, including on normally flammable surfaces thanks to the F mark. At 49 mm deep it stays discreet in corridors, on external stairs and around halls. Use the IP65 version where the fitting takes direct rain or regular washdown rather than occasional splashing.

Frequently asked questions

Is IP44 enough for outdoor use? For sheltered areas or occasional splashing, yes. For direct exposure to rain, order the IP65 version.

How many fittings does a garage need? That depends on the floor area and the version. The 3 LED build at 7.5 W with omnidirectional light covers more than the single LED build.

Can I run it from a 12 V battery? Yes, if you order the 12-24 V DC version. The standard supply is 230 V AC.
