Apolo-Ex ATEX LED Floodlight 12 LEDs 30W for Industrial Halls

Apolo-Ex ATEX LED Floodlight 12 LEDs 30W for Industrial Halls

The Apolo-Ex ATEX LED floodlight 30W is the compact model of the series, with 12 LEDs and 270 x 135 x 150 mm. You install it in warehouses, covered car parks and potentially explosive areas where you need many smaller light points. Designed and manufactured in Europe.

Benefits of the Apolo-Ex ATEX LED floodlight 30W

• Low power, high efficiency: 30 W at 110 lm/W suits distributed lighting across large floor areas.
• ATEX certification: general lighting in group II zone 2 and group III zone 22.
• Small footprint: at 270 mm long, it mounts easily on flat surfaces, including spaces with low ceilings.
• Selectable optics: wide, medium or omnidirectional focus, chosen to match the mounting height.
• Universal voltage: supply from 90 to 230 V, 50/60 Hz, with the driver inside the housing.
• Durable build: IK10, powder-coated aluminium housing and a UV protected diffuser.

Technical specifications

• Housing material: powder-coated aluminium
• Diffuser: clear polycarbonate, UV protected
• Housing colour: other colours available on customer request
• Number of LEDs: 12
• Power per LED: 2.5 W
• Total power: 30 W
• Light source: high power OSRAM LEDs
• Luminous efficacy: 110 lm/W
• Colour rendering index: 80 for neutral and warm white, 70 for cool white
• LED colour (option): neutral white 4000 K or cool white 5000 K
• Beam focus (option): wide, medium, omnidirectional
• Supply: 90-230 V AC, 50/60 Hz
• Driver: included, inside the housing
• Electrical insulation class: I
• Ingress protection: IP65 minimum, IP66 per the environmental datasheet
• Impact resistance: IK10
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 270 x 135 x 150 mm
• Weight: 7.6 kg
• Certifications and markings: ATEX (group II zone 2, group III zone 22), CE, F-Mark
• Use: indoor

Applications and installation

The luminaire covers industrial and ATEX duties: warehouse lighting, car park lighting and lighting in potentially explosive atmospheres. Fix it to a flat surface. The F marking allows direct mounting on normally flammable surfaces. For car parks and warehouse aisles, the wide focus gives an even distribution at low mounting heights. The zone 22 certification covers areas where combustible dust is present.

Frequently asked questions

Is a 30 W floodlight enough for a warehouse? The model is designed for distributed lighting, with several 30 W units placed evenly. For strong single points, the series offers 36 and 48 LED versions.

Which supply voltage does it accept? From 90 to 230 V, 50/60 Hz, with the driver inside the housing.

Can you install it in a combustible dust area? Yes, the ATEX certification covers group III zone 22. Check the exact classification of your own zone.
