Inverter Growatt SPH 10000TL3 BH-UP
Cere oferta Cere oferta
SKU:
SPH 10000TL3 BH-UP
Categories: Growatt Energy, Growatt inverter, Hybrid Inverters
Tags: growatt, hybrid inverter, Inverter, solar
Description
Technical Specifications of Growatt SPH 10000TL3 BH-UP Three-Phase Hybrid Inverter
| Feature | Specification |
|---|---|
| Model | Growatt SPH 10000TL3 BH-UP |
| Inverter Type | Three-phase hybrid inverter (on-grid + battery) |
| Rated AC Power | 10,000 W |
| Max AC Apparent Power | 10,000 VA |
| Recommended Max DC Input Power | 15,000 W |
| Max DC Input Voltage | 1,000 V |
| Start-up Voltage | 120 V |
| MPPT Voltage Range | 120–1,000 V |
| Number of MPPT Trackers | 2 |
| PV Strings per MPPT | 1 |
| Battery Voltage Range | 100–550 V DC |
| Battery Type | Lithium or Lead-Acid |
| Max Charge/Discharge Current | 25 A |
| Continuous Charge/Discharge Power | 10,000 W |
| Max AC Output Power | 10,000 W |
| Max AC Output Current | 15.2 A |
| Nominal AC Voltage | 380/400 V (310–476 V) |
| Grid Frequency | 50/60 Hz (45–55 Hz / 55–65 Hz) |
| Adjustable Power Factor | 0.8 leading to 0.8 lagging |
| THDi (Total Harmonic Distortion) | < 3% |
| Grid Connection Type | 3 Phase + Neutral + Ground (3W+N+PE) |
| UPS Transfer Time | < 10 ms |
| Max Efficiency | 98.2% |
| European Efficiency | 97.4% |
| Protection Rating | IP65 (suitable for outdoor installation) |
| Dimensions (W × H × D) | 505 × 453 × 198 mm |
| Weight | 31 kg |
| Operating Temperature Range | –25 to +60 °C |
| Night Power Consumption | < 1 W |
| Cooling Method | Fanless (natural convection) |
| VPP System Compatible | Yes, via VPP interface |
| Smart Load Control | Via dry contact |
| Certifications | CE, IEC62109, IEC62040, VDE-AR-N 4105, EN50549-1, CEI 0-21, CEI 0-16, G98 |
| Warranty | 10 years |
Additional information
| Weight | 31 kg |
|---|---|
| Dimensions | 50,5 × 45,3 × 19,8 cm |
| Brand | Growatt |
Reviews (0)
Only logged in customers who have purchased this product may leave a review.
About brand
Growatt: Leading Global Supplier of Smart Energy Solutions
Growatt is a global leader that offers comprehensive solar energy solutions. Growatt specializes in the research and development and manufacturing of a wide range of products. These products include PV inverters, energy storage systems (ESS), smart energy management solutions, and EV chargers.
In Europe& Middle East, Ecosolaris is a key partner and authorized distributor of Growatt solutions. This partnership helps homeowners and companies optimize energy consumption and accelerate the transition to sustainable energy sources through Growatt products.
Growatt products are known for high efficiency, reliability, and robust service support. They are widely used in residential, commercial, and utility-scale projects. Growatt helps homeowners and businesses optimize energy use and speed up the shift to sustainable energy.
