Helios Architectural LED Floodlight 3 LEDs 7.5W

Helios Architectural LED Floodlight 3 LEDs 7.5W

The Helios architectural LED floodlight carries 3 LEDs in a small ornamental body for accent light on facades, walkways and steps. It answers architects and owners who want discreet points of light recessed into flat surfaces. The polycarbonate housing and IP67 rating solve mounting where water collects and people walk.

Benefits

• Discreet: at 120 x 80 x 80 mm and 0.4 kg, the body disappears into paving or wall.
• Recessed anywhere: horizontal or vertical flat surfaces, with a reflector rated for pedestrian and light vehicle traffic.
• Focused output: OSRAM LEDs with lenses, white or coloured, from 250 lm per LED in cool white.
• Sealed optics: both the optical compartment and the driver are protected to IP67.
• No external driver: the power unit sits inside the housing and the fitting connects directly to 230 V AC.
• Practically maintenance free: long LED life avoids reopening the paving.

Technical specifications

• Housing material: polycarbonate
• Housing colour: black as standard
• Diffuser: clear polycarbonate
• Light source: OSRAM LEDs with lenses, white or coloured
• Number of LEDs: 3
• Power per LED: 2.5 W
• Total power: 7.5 W
• Luminous output: min. 250 lm/LED cool white, min. 200 lm/LED warm white
• CRI: 80 for neutral and warm white, 70 for cool white
• Supply: 230 V AC
• Power unit: included, inside the housing
• Supply cable length: 2 m
• Insulation class: III
• Ingress protection: IP67
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 120 x 80 x 80 mm
• Weight: 0.4 kg

Applications and installation

The main use is architectural lighting. Recess the body into floors, steps, parapets or walls, horizontally or vertically. The robust reflector takes pedestrian and light vehicle traffic, so you can place it on access driveways as well. The 2 m cable reaches the junction box. IP67 sealing suits surfaces that are hosed down or exposed to standing water after cleaning, and the polycarbonate body carries no metal that would show corrosion at the paving line.

Frequently asked questions

Can I choose coloured LEDs? Yes. The construction accepts white or coloured LEDs, each focused through a lens.

Do I need a separate transformer? No. The power unit is built into the housing and the standard supply is 230 V AC.

Does it survive rain and floor washing? Yes. The IP67 rating covers both the optical compartment and the driver.
