Description
Technical Specifications of Growatt MID 25KTL3-X Three-Phase On-Grid Inverter
| Feature | Specification |
|---|---|
| Model | Growatt MID 25KTL3-X |
| Inverter Type | Three-phase on-grid inverter (commercial/industrial) |
| Max Recommended PV Power | 32,500 W |
| Max DC Input Voltage | 1,100 V |
| Start Voltage | 250 V |
| Nominal DC Voltage | 580 V |
| MPPT Voltage Range | 200–1,000 V |
| Number of MPPT Trackers | 2 |
| Strings per MPPT | 2 |
| Max Input Current per MPPT | 27 A |
| Max Short-Circuit Current/MPPT | ~33 A |
| AC Nominal Output Power | 25,000 W |
| Max AC Apparent Power | ~27,500 VA |
| Nominal AC Voltage / Grid Range | 230 V / 400 V (340–440 V) |
| Grid Frequency Range | 50/60 Hz (45–65 Hz) |
| Max Output Current | ~38.5 A |
| Adjustable Power Factor | From 0.8 leading to 0.8 lagging |
| THDi | < 3 % |
| Max Efficiency | ~98.75 % |
| European Efficiency | ~98.6 % |
| MPPT Efficiency | ~99.9 % |
| Protection Features | DC/AC Type II SPD, DC reverse polarity, DC switch, ground-fault, AC short-circuit, anti-islanding, string monitoring; AFCI optional |
| Display & Connectivity | OLED + touch key display, RS-485, USB; Wi-Fi/GPRS/4G optional |
| Cooling Method | Smart air cooling (fan) |
| Design | Transformerless |
| Protection Rating | IP65 |
| Dimensions (W × H × D) | ~525 × 395 × 222 mm |
| Weight | ~23 kg |
| Noise Emission (Typical) | ≤ 40 dB(A) |
| Self-Consumption (Night) | < 1 W |
| Operating Altitude | Up to 4,000 m |
| Operating Temperature Range | –25 °C to +60 °C (derating above +45 °C) |
| Humidity Tolerance | 0–100 % relative humidity |
| Warranty | 5 years standard (extendable) |
A renowned producer of photovoltaic inverters, Growatt makes the Growatt MID 25KTL3-X solar inverter. Large-scale commercial and industrial solar power systems are the target market for MID-25KTL3-X.
- High and maximum efficiencies of up to 98.7% aid in the most efficient conversion of solar panel energy into electrical power.
- Due to this inverter’s dual MPP tracker function, the system’s overall energy production may be maximized by controlling numerous strings of solar panels with various orientations or shading circumstances.
- Additionally, the inverter can accommodate a wide input voltage range, enabling it to function with various solar panel layouts.
- Built-in DC switches The integrated DC switches in this inverter improve safety during setup and maintenance.
- Another choice is the adaptable monitoring inverter, which enables customers to track the operation of their solar power system in real-time and may be linked to monitoring systems by Ethernet, Wi-Fi, or RS485 interfaces.
- Modern grid support features like reactive power regulation and low voltage (LVRT) assure the reliability and grid compatibility of the solar system.
Additional information
| Weight | 23 kg |
|---|---|
| Dimensions | 52,5 × 39,5 × 22,2 cm |
| Brand | Growatt |
