Inverter Growatt MID 40KTL3-X Three‑phase on‑grid
6.680,55 AED
Description
Technical Specifications of Growatt MID 40KTL3-X Three-Phase On-Grid Inverter
| Feature | Specification |
|---|---|
| Model | Growatt MID 40KTL3-X |
| Inverter Type | Three-phase on-grid |
| Rated AC Power | 40,000 W |
| Max Recommended PV Power | 52,000 W (STC) |
| Max DC Input Voltage | 1,100 V |
| Start-up Voltage | 250 V |
| Nominal DC Voltage | 580 V |
| MPPT Voltage Range | 200–1,000 V |
| Number of MPPT Trackers | 2 |
| PV Strings per MPPT | 2 |
| Max Input Current per MPPT | 25–27 A |
| Max Short-Circuit Current/MPPT | ~32 A |
| Nominal AC Voltage / Grid Range | 230 V / 400 V (340–440 V) |
| Grid Frequency Range | 50/60 Hz (45–65 Hz) |
| Max Output Current | ~63.5 A |
| Adjustable Power Factor | 0.8 leading to 0.8 lagging |
| THDi (Total Harmonic Distortion) | < 3% |
| Max Efficiency | ~98.75% |
| European Efficiency | ~98.6% |
| MPPT Efficiency | ~99.9% |
| Protection Features | DC/AC Type II SPD, DC reverse polarity, DC switch, ground-fault, AC short-circuit, anti-islanding, string monitoring; AFCI optional |
| Display & Connectivity | OLED + touch key display, RS-485, USB; Wi-Fi/GPRS/4G optional |
| Cooling Method | Smart air cooling (fan) |
| Design | Transformerless |
| Protection Rating | IP65 |
| Dimensions (W × H × D) | ~525 × 395 × 222 mm |
| Weight | ~43 kg |
| Noise Emission (Typical) | ≤ 40 dB(A) |
| Self-Consumption (Night) | < 1 W |
| Operating Altitude | Up to 4,000 m |
| Operating Temperature Range | –25 °C to +60 °C (derating above +45 °C) |
| Humidity Tolerance | 0–100% relative humidity |
| Warranty | 5 years standard (extendable) |
- High Conversion Efficiency: The inverter provides high conversion efficiency, guaranteeing that the solar panels provide the most electricity possible.
- Three-Phase Output: Because it offers a three-phase output, it may be used in commercial and industrial settings.
- Advanced MPPT Technology: By drawing the most electricity possible from the solar panels, the inverter uses Maximum electricity Point Tracking (MPPT) technology to maximize its performance.
- broad Input Voltage Variety: The versatility of constructing solar systems with various panel configurations is made possible by the MID-40KTL3-X’s ability to tolerate various input voltages.
- secure and dependable: To provide a secure and dependable operation, The inverter has some protective features, including anti-islanding prevention, overvoltage protection, overload protection, and temperature protection.
- Integrated Monitoring and Communication: The inverter has built-in monitoring and communication features that make it simple to integrate it with external monitoring systems and enable remote system performance monitoring.
- Smart Grid Support: It supports grid-connected solar systems and complies with the requirements of smart grid integration.
Additional information
| Weight | 43 kg |
|---|---|
| Dimensions | 52,5 × 39,5 × 22,2 cm |
| Brand | Growatt |
