LS-06 Recessed LED Emergency Luminaire 2W

LS-06 Recessed LED Emergency Luminaire 2W

The LS-06 recessed LED emergency luminaire marks escape routes in offices, schools and hospitals with plasterboard ceilings. It solves a specific problem: you need a legible exit pictogram without a housing that breaks a clean ceiling line. After installation only the diffuser remains visible, and the symbol stays readable from 25 m.

Benefits

• Flush ceiling integration: the body sits inside the plasterboard, so no surface box interrupts the ceiling plane.
• Readable at 25 m: 4 high-power OSRAM LEDs light two curved plates evenly across the whole pictogram.
• High contrast symbol: red or green LEDs light the background while white LEDs light the ideogram.
• Three hours of autonomy: the built-in NiMH batteries take over the instant mains power fails.
• Status you can read: the front charging indicator LED shows battery condition during a walk-through.
• 2W total draw: permanent operation adds almost nothing to the energy bill.

Technical specifications

• Operating principle: fibre optic, through two curved plastic plates
• Mounting: recessed in plasterboard
• Housing material: anodised aluminium (electrostatically painted sheet)
• Housing colour: black (standard)
• Diffuser: transparent plexiglass, legend printed to order
• Light source: 4 high-power OSRAM LEDs
• LED colours: red or green background, white ideogram
• Viewing distance: up to 25 m
• Total power: 2W
• Power supply: 230V AC, 50Hz
• Batteries: NiMH, minimum 3 hours of autonomy
• Electrical protection class: III
• Ingress protection: IP40
• Operating temperature: 0 to +40 degrees C
• Dimensions: 340 x 150 x 100 mm
• Weight: 0.9 kg

Applications and installation

Use the LS-06 recessed LED emergency luminaire in offices, schools, hospitals, hotels and retail units fitted with suspended plasterboard ceilings. Cut the ceiling to the body size, seat the luminaire and connect it to 230V AC. Choose the ideogram to match your evacuation plan. The IP40 rating and the 0 to +40 degrees C range limit the product to dry, climate-controlled interiors, so it suits air-conditioned buildings across the Gulf rather than open or semi-outdoor areas. Keep the front indicator visible for routine inspection.

Frequently asked questions

How does the LS-06 differ from the LS-05? The LS-06 is recessed into plasterboard, uses curved plates, has a black housing and a 25 m viewing distance. The LS-05 is surface mounted on a wall or ceiling.

How many LEDs does it use? Four high-power OSRAM LEDs, with the colour selected to match the ideogram you order.

How long does it run without mains power? A minimum of 3 hours on the integrated NiMH batteries.
