Flexiray P Recessed LED Spotlight 6W CRI90

Flexiray P Recessed LED Spotlight 6W CRI90

The Flexiray P recessed LED spotlight is a fixed 6 W fitting with a 30 degree beam, CRI 90 and a unified glare rating of no more than 13. It is intended for offices, hotel rooms, restaurants and corridors where the eye should see the effect of the light on a desk, a wall or a floor, never the source itself.

Benefits

• Minimal glare: a UGR of 13 or less at X=4H, Y=8H means comfort at screens and desks, without distracting reflections.
• Faithful colour: CRI 90 makes timber, textiles and food look natural rather than washed out.
• Matched tint between fittings: a chromatic tolerance below 3 SDCM (ANSI) is tight, so a row of spotlights looks uniform.
• Simple installation: the driver sits inside the housing, so you have no separate gear to conceal above the ceiling.
• Discreet linear format: the 150 x 45 mm body reads as a white slot in a suspended ceiling, not as a visible circle.

Technical specifications

• Mounting type: recessed in ceiling
• Material: aluminium
• Colour: white RAL9010
• Power: 6 W
• Luminous flux: 585 lm
• Luminous efficacy: 75 lm/W
• Optical efficiency: 88 %
• Optic: medium, 30 degree beam
• Glare rating: UGR 13 or less (X=4H, Y=8H)
• Colour temperature (CCT): 3000 K or 4000 K
• Colour rendering index: CRI 90
• Colour consistency: SDCM below 3 (ANSI)
• Control: on/off
• Supply voltage: 220 – 240 V AC
• Ingress protection: IP20
• Electrical class: II
• Driver included: yes, integrated in the housing
• Adjustable: no
• Dimensions: 150 x 45 x 60 mm

Applications and installation

Fit the body into suspended ceilings in open-plan offices, meeting rooms, hotel rooms and corridors, restaurants and consulting rooms. The fixed 30 degree beam of this Flexiray P recessed LED spotlight suits accent light over tables, reception desks and picture walls. IP20 reserves it for dry interiors. It wires straight to 220-240 V AC and switches from the wall. Design and assembly are carried out in Europe.

Frequently asked questions

Why does UGR 13 or less matter? A low glare rating means the source is well hidden in the body and throws no reflections onto screens or glossy surfaces. It is a standard requirement in office projects.

Can I aim the beam? No. Flexiray P is a fixed body. Plan its position on the ceiling layout so the 30 degree beam lands where you need it.

How bright is it? The fitting delivers 585 lm from 6 W. It is an accent and comfort spotlight, not a general lighting unit; add further fittings for the ambient level.
