Topaz 24 Street LED Luminaire 120W

Topaz 24 Street LED Luminaire 120W

The Topaz 24 street LED luminaire is a 120 W pole-mounted unit producing up to 15487 lm at 129 lm/W. It suits municipalities, car park operators and developers replacing ageing street lanterns with a rugged IP66/IK10 body and road-specific optics. One fitting covers a wide carriageway.

Benefits

• High output per pole: up to 15487 lm and 129 lm/W from 120 W cuts the connected load on every column.
• Dedicated road optic: the street distribution puts light on the carriageway; narrow, medium, wide and extra wide are available instead.
• Extruded aluminium housing: the 586 x 248 x 63 mm profile handles weather exposure on open sites.
• Sealed against dust and rain: IP66 blocks driven dust and water, a real concern on Gulf roads and yards.
• Vandal resistant: the IK10 rating covers impact in publicly accessible locations.
• Aim it on site: the adjustable pole bracket sets the tilt angle during installation.

Technical specifications

• Mounting: pole mounted, adjustable bracket
• Material: extruded aluminium
• Finish: grey RAL7040, electrostatic powder coated
• Power: 120 W
• Luminous flux: 14672-15487 lm
• Luminous efficacy: 122-129 lm/W
• Optics: street, narrow, medium, wide, extra wide
• Colour temperature: 4000 K or 5000 K
• CRI: 80
• Control: on/off
• Ingress protection: IP66, IK10
• Insulation class: I
• Driver included: yes
• Dimensions: 586 x 248 x 63 mm

Applications and installation

Mount the Topaz 24 street LED luminaire on public lighting columns along streets, boulevards, estate roads, car parks, logistics yards and industrial perimeters. Choose the street optic for carriageways and the extra wide optic for parking decks and open squares. Set the tilt on the adjustable bracket, then confirm spacing against pole height. Grey RAL7040 powder coating and the extruded aluminium body suit exposed installations, while the sealed IP66 gear tray keeps blown dust away from the driver compartment. Specify 4000 K in residential districts and 5000 K on arterial roads. The product is engineered and built in Europe.

Frequently asked questions

What output does the street optic give? It delivers 14672 lm at 122 lm/W. The wide optic reaches 15487 lm.

Can the luminaire be tilted? Yes. The pole bracket is adjustable, so you set the aiming angle at installation.

Is it dimmable? The catalogue version is on/off only.
