Office Line 1100 Suspended LED Luminaire 40W Indoor

Office Line 1100 Suspended LED Luminaire 40W Indoor

The Office Line 1100 suspended LED luminaire is a 1100 mm linear profile that emits light upwards and downwards at the same time. It is specified by office fit-out firms, interior architects and workplace managers. It removes the hard contrast between desk and ceiling: the upper side lights the soffit while the lower side delivers task light at CRI 90.

Benefits

• Direct and indirect light: the up and down emission softens shadows and reduces visual fatigue at the desk.
• Faithful colour: CRI 90 with SDCM under 3 (ANSI) consistency between fittings in a run.
• Slim section: only 25 mm wide by 100 mm high, in a discreet anodised black finish.
• Low voltage supply: 24 V DC lets one power supply feed several luminaires.
• Wide optic: even distribution across the desk surface, with no dark patches.
• Office environment: IP20, insulation class I and suspended mounting with the dedicated kit.

Technical specifications

• Mounting type: suspended, with suspension mounting kit
• Housing material: anodised aluminium
• Colour: RAL9010 anodised black
• Power: 40 W
• Luminous flux: 2638 lm
• Luminous efficacy: 66 lm/W
• Light direction: up and down
• Optic: wide
• Colour temperature: 4000 K
• CRI: 90
• Colour consistency: SDCM under 3 (ANSI)
• Control: on/off
• Ingress protection: IP20
• Insulation class: I
• Power supply: 24 V DC, driver not included
• Dimensions: 1100x25x100 mm

Applications and installation

The Office Line 1100 luminaire is made for open-plan offices, meeting rooms, receptions, libraries and coworking floors. Suspend it above workstations or above the meeting table. Several luminaires align in rows that follow the desk layout. Power comes from a 24 V DC supply sized separately for the number of fittings on the circuit. With IP20 protection it stays indoors, in conditioned workplaces. Designed and produced in Europe.

Frequently asked questions

Is the power supply included? No. The Office Line 1100 luminaire runs at 24 V DC and the supply is selected according to the number of fittings on the circuit.

Can it be dimmed? The catalogue version is on/off. Discuss dimming requirements with our team before ordering.

Why does CRI 90 matter in an office? Colour rendering close to daylight makes documents, screens and materials show their real tones.
