Atlas Recessed LED Floodlight 24 LEDs 24W Outdoor

Atlas Recessed LED Floodlight 24 LEDs 24W Outdoor

The Atlas recessed LED floodlight with 24 LEDs is built for architects, landscape designers and public space managers who need accent light in paving or walls. It sets into any flat surface and takes pedestrian or light vehicle traffic. The 8 mm toughened glass and IP67 rating remove the worry of fittings that crack or flood.

Benefits

• Withstands foot traffic: the 8 mm toughened glass diffuser and stainless steel flange carry pedestrian and light vehicle loads.
• Water stays out: optical compartment and driver are sealed to IP67, suitable for in-ground mounting.
• High output: 24 OSRAM LEDs of 1 W deliver minimum 250 lm per LED in cool white and 200 lm per LED in warm white.
• Beam of your choice: wide, medium, narrow or elliptical focus, according to the effect you want on the facade.
• Power unit included: the driver sits inside the housing, so the 12-24 V DC supply needs no separate enclosure.
• Practically maintenance free: the LED service life avoids reopening the paving.

Technical specifications

• Housing material: powder-coated aluminium with stainless steel cover
• Diffuser: 8 mm toughened glass
• Flanges: stainless steel
• Light source: OSRAM LEDs
• Number of LEDs: 24
• Power per LED: 1 W
• Total power: 24 W
• LED colours: warm white 3000 K, neutral white 4000 K, cool white 5000 K, red 650 nm, green 523 nm, blue 470 nm, orange 617 nm
• Beam focus: wide, medium, narrow, elliptical
• Luminous output: min. 250 lm/LED cool white, min. 200 lm/LED warm white
• CRI: 80 for neutral and warm white, 70 for cool white
• Supply: 12-24 V DC standard, 230/240 V AC optional
• Power unit: included, inside the housing
• Supply cable length: 2 m
• Insulation class: III
• Ingress protection: IP67
• Operating temperature: -20 degrees C to +40 degrees C
• Dimensions: 245 x 40 mm
• Mounting hole diameter: 245 mm
• Hole depth for in-ground mounting: 40 mm
• Weight: 2.5 kg
• Markings: CE, F mark for mounting on normally flammable surfaces, outdoor use

Applications and installation

The floodlight covers commercial, residential, public and architectural work, in garden lighting, accent lighting and recessed lighting. Set it into paving, steps, kerbs or walls, horizontally or vertically. You need a 245 mm cut-out and 40 mm of depth. For facades choose the narrow or elliptical focus, and for walkways the wide beam. IP67 sealing suits surfaces that are washed down or hold water after cleaning.

Frequently asked questions

Can cars drive over it? The reflector is built for pedestrian and light vehicle traffic, thanks to the 8 mm toughened glass and the stainless steel cover.

Can I mix coloured LEDs? Yes. Besides the three shades of white, red, green, blue and orange are available. State the colour when you order.

Which supply voltage do I use? 12-24 V DC as standard, with the power unit inside the housing. On request the fitting is supplied for 230 V AC.
