Apron LED Floodlight 300-450W for Airport Aprons

Apron LED Floodlight 300-450W for Airport Aprons

This Apron LED floodlight is a high-power fitting for the airport apron. It serves airport authorities and ground handling operators who light boarding, loading and aircraft parking surfaces. Nine Bridgelux COB LEDs, running at 300-450 W, deliver a minimum luminous flux of 45,000 lm from a single body.

Benefits

• High output for large surfaces: at least 45,000 lm from one fitting, produced by 9 high-power COB LEDs.
• Truthful colour: colour rendering index 80 in neutral white and 70 in cool white, which helps visual aircraft inspection.
• Concentrated beam: a narrow focus made for tall masts along the edge of the apron.
• Efficient on the grid: power factor above 0.95 and a universal 90-230 V AC, 50-60 Hz input.
• Built for outdoors: electrostatically painted extruded aluminium, UV-protected diffuser, IP65 and IK10, with a rated ceiling of +50 degrees C.
• Specifiable: you choose the colour temperature, and other housing colours are available on request.

Technical specifications

• Housing material: extruded aluminium, electrostatically painted
• Housing colour: other colours on customer request
• Diffuser: clear polycarbonate, UV protected
• Light source: 9 high-power Bridgelux COB LEDs
• Number of LEDs: 9
• LED colour options: neutral white 4000 K, cool white 5000 K
• Beam focus: narrow
• Luminous flux: minimum 45,000 lm
• Colour rendering index: 80 (neutral white), 70 (cool white)
• Total power: 300-450 W
• Driver: included
• Power supply: 90-230 V AC, 50-60 Hz (230 V 50 Hz standard)
• Power factor: above 0.95
• Electrical insulation class: I
• Ingress protection: IP65
• Impact protection: IK10
• Operating temperature: -40 degrees C to +50 degrees C
• Dimensions: 750 x 400 x 300 mm
• Weight: 11 kg
• Markings: CE, F-Mark, outdoor use

Applications and installation

Use the floodlight for airport lighting, above all on boarding and aircraft parking aprons. Mount it on masts or tall structures and aim the narrow beam at the working area. Pick neutral white 4000 K when ground crews need better colour rendering, and cool white 5000 K for maximum contrast. The input accepts any supply between 90 and 230 V AC, and the IP65 sealing keeps apron dust out of the optical chamber. Designed and manufactured in Europe.

Frequently asked questions

What output does the Apron LED floodlight give? A minimum of 45,000 lm, from 9 Bridgelux COB LEDs at a total power of 300-450 W.

What is the difference between the 4000 K and 5000 K versions? Neutral white 4000 K has a colour rendering index of 80, cool white 5000 K has 70. Both use the same narrow optic.

Can I order a different housing colour? Yes, other housing colours are available on customer request.
